Workplace Collaborations v1

extensions [nw]

breed [rooms room]
breed [people person]

turtles-own [
  bathroom-countdown
  drink-countdown
  food-countdown
  research-countdown
  turned-blue-at
  duration-blue
  interest
  office
  standing
  num-projects
  path-to-bathroom
  path-to-drinking-fountain
  path-to-cafeteria
  path-counter
  destination
  path-to-destination
]

globals [ bathroom cafeteria drinking-fountain wall-color office-color
  hallway-color drinking-fountain-color cafeteria-color bathroom-color
  color1 ]

to setup
  if (count links != 0) [stop] ;;safeguard against hitting setup when you don't need to

  ;;to make sure there are the right number of communal locations:
  if (count patches with [pcolor = bathroom-color] != 1 or count patches with [pcolor = drinking-fountain-color] != 1
    or count patches with [pcolor = cafeteria-color] != 1) [
    user-message("Don't forget to add exactly one bathroom, drinking fountain, and cafeteria!")
    stop
    ]

  ;;true setup starts here
  ask one-of patches with [pcolor = bathroom-color] [
    set bathroom self
  ]
  ask one-of patches with [pcolor = cafeteria-color]  [
    set cafeteria self
  ]
  ask one-of patches with [pcolor = drinking-fountain-color] [
    set drinking-fountain self
  ]

  ;;create turtles (rooms) on every patch in order to use the nw extension
  ask patches [
    sprout 1 [
      set color [pcolor] of self
      set breed rooms
      set shape "square"
    ]
  ]

  ;;make sure the communal areas are rooms (turtles), not patches
  set bathroom one-of rooms-on bathroom
  set drinking-fountain one-of rooms-on drinking-fountain
  set cafeteria one-of rooms-on cafeteria

  ;;create a lattice with every room connected to its neighboring rooms that are not walls
  ask rooms with [color != wall-color] [
    create-links-with rooms-on ([neighbors4] of patch-here) with [pcolor != wall-color]
  ]
  ask links [hide-link]

  nw:set-snapshot rooms links

  ask people [hatch 1 die] ;;to make sure the people are on top of the rooms
  ask people [assign-office] ;;an employee's office is where he is placed in the beginning
  clear-plot
  reset-ticks
end

to go
  ask people [
    move
    set-destination
  ]
  ask people with [color = blue] [  ;;blue color = wants research, red color = doesn't
    if (count other people in-radius 2 with [color = blue] = 1) [
      interact
    ]
  ]
  ask people with [color = red] [
    set research-countdown research-countdown - 1
    if research-countdown <= 0 [
      set color blue
      ask my-links [die]
      set turned-blue-at ticks
    ]
  ]
  tick
end

to move ;;turtle procedure

  if (bathroom-countdown > 0 and food-countdown > 0 and drink-countdown > 0 and one-of rooms-here != office) [
    move-toward-destination
  ]
  if bathroom-countdown <= 0 [
    set destination bathroom
    set path-to-destination path-to-bathroom
    move-toward-destination
  ]
  if (drink-countdown <= 0 and bathroom-countdown > 0) [ ;;bathroom > drink
    set destination drinking-fountain
    set path-to-destination path-to-drinking-fountain
    move-toward-destination
  ]
  if (food-countdown <= 0 and bathroom-countdown > 0 and drink-countdown > 0) [
    set destination cafeteria
    set path-to-destination path-to-cafeteria
    move-toward-destination
  ]
end

to set-destination ;;turtle procedure
  if (one-of rooms-here = bathroom and destination = bathroom) [
    set bathroom-countdown random 1000
    set path-counter 0
    set destination office
    set path-to-destination reverse path-to-destination
  ]
  if (one-of rooms-here = drinking-fountain and destination = drinking-fountain) [
    set drink-countdown random 1000
    set path-counter 0
    set destination office
    set path-to-destination reverse path-to-destination
  ]
  if (one-of rooms-here = cafeteria and destination = cafeteria) [
    set food-countdown random 2000
    set path-counter 0
    set destination office
    set path-to-destination reverse path-to-destination
  ]
  if (one-of rooms-here = office) [
    set path-counter 0
    set bathroom-countdown bathroom-countdown - 1
    set drink-countdown drink-countdown - 1
    set food-countdown food-countdown - 1
  ]
end

to assign-attributes ;;turtle procedure
  set breed people
  set color blue
  set shape "person"
  set size 2
  set bathroom-countdown random 1000
  set drink-countdown random 1000
  set food-countdown random 2000
  set standing random-float 5
  set turned-blue-at 0
  set duration-blue 0
  set num-projects 0
end

to declare-colors
  set wall-color yellow
  set office-color black
  set hallway-color gray
  set drinking-fountain-color blue
  set cafeteria-color red
  set bathroom-color green
end

to assign-office ;;turtle procedure
  let temp 0
  set office one-of rooms-here
  ask office[set temp nw:turtles-on-path-to bathroom]
  set path-to-bathroom temp
  ask office[set temp nw:turtles-on-path-to drinking-fountain]
  set path-to-drinking-fountain temp
  ask office[set temp nw:turtles-on-path-to cafeteria]
  set path-to-cafeteria temp
  set path-counter 0
end

to create-random ;;creates a random number of turtles in areas that are of office-color
  ask people [die]
  crt number [assign-attributes
    move-to one-of patches with [pcolor = office-color and count people-here = 0]
  ]
end

to interact ;;turtle procedure
  if random-float 1 < (1 - sqrt(1 - (interact-probability / 100))) [ ;;if each person interacts with this probability, the total probaiblity of interaction is interact-probability
    let partner one-of other people in-radius 2 with [color = blue]
    set color red
    set research-countdown 1000
    set num-projects num-projects + 1
    set duration-blue ((ticks - turned-blue-at) + duration-blue)
    ask partner [set color red set research-countdown 1000 set num-projects num-projects + 1
      set duration-blue ((ticks - turned-blue-at) + duration-blue)]
    create-link-with partner [set color red]
  ]
end

to move-toward-destination ;;turtle procedure
  let closest one-of rooms-here
  if (path-counter < length path-to-destination - 1) [
    set path-counter path-counter + 1
    set closest item path-counter path-to-destination]
  move-to closest
end

to-report average-blue  ;;reports the average amount of time (in ticks) a person goes without a research project
  report mean ([duration-blue / num-projects] of people with [num-projects > 0])
end



;;used to make and import layouts of workplaces

to create-layout
  reset-ticks
  declare-colors
  if mouse-down? [
    let x round mouse-xcor
    let y round mouse-ycor
    if (Layout-options = "person") [
      ask patch x y [
        if (count people-here = 0) [sprout 1 [assign-attributes]]
      ]
    ]
    if (Layout-options = "walkable-space") [
      ask patch x y [set pcolor office-color]
    ]
    if (Layout-options = "bathroom") [
      ask patch x y [set pcolor bathroom-color]
    ]
    if (Layout-options = "drinking-fountain") [
      ask patch x y [set pcolor drinking-fountain-color]
    ]
    if (Layout-options = "cafeteria") [
      ask patch x y [set pcolor cafeteria-color]
    ]
    if (Layout-options = "wall") [
      ask patch x y [set pcolor wall-color]
    ]
    if (Layout-options = "desk") [ ;;a desk is a solid, unwalkable rectangle
      ask patches with [pxcor <= x + width / 2 and pycor <= y + height / 2 and pxcor > x - width / 2 and pycor > y - height / 2]  [
        set pcolor yellow
      ]
    ]
    if (Layout-options = "cubicle") [ ;;a cubicle is a rectangular room surrounded by walls
      ask patches with [(pxcor = ceiling(x + width / 2) and (pycor <= ceiling(y + height / 2) and pycor >= ceiling(y - height / 2)))
         or (pycor = ceiling(y + height / 2) and (pxcor <= ceiling(x + width / 2) and pxcor >= ceiling(x - width / 2)))
         or (pxcor = ceiling(x - width / 2) and (pycor <= ceiling(y + height / 2) and pycor >= ceiling(y - height / 2)))
         or (pycor = ceiling(y - height / 2) and (pxcor <= ceiling(x + width / 2) and pxcor >= ceiling(x - width / 2)))]
         [set pcolor yellow]
    ]
    tick
  ]
end

to clear
  ca
end

to export-layout
  export-world "Open-office-layout"
end

to import-layout
  import-world "Open-office-layout"
end


;;these are all of the pre-made layouts the correspond to buttons

to cubicle-layout1
  import-world "Cubicle-layout1"
  setup
end

to cubicle-layout2
  import-world "Cubicle-layout2"
  setup
end

to the-office-layout
  import-world "The-Office-Layout"
  setup
end

to free-for-all
  import-world "free-for-all"
  create-random
  setup
end

to open-office
  import-world "Open-office-layout"
  setup
end

to cubicle-layout1-centralized
  import-world "Cubicle-layout1-centralized"
  setup
end

to Analysis-template
  import-world "Analysis-template"
end

to Centralized-doors-down
  import-world "Centralized-doors-down"
  setup
end

to Centralized-no-walls
  import-world "Centralized-no-walls"
  setup
end

to Uncentralized-inline-doors-down
  import-world "Uncentralized-inline-doors-down"
  setup
end

to Uncentralized-scattered-doors-down
  import-world "Uncentralized-scattered-doors-down"
  setup
end

to Centralized-fewer-hallways
  import-world "Centralized-fewer-hallways"
  setup
end

to Uncentralized-inline-fewer-hallways
  import-world "Uncentralized-inline-fewer-hallways"
  setup
end

to Uncentralized-scattered-fewer-hallways
  import-world "Uncentralized-scattered-fewer-hallways"
  setup
end

to Uncentralized-scattered-no-walls
  import-world "Uncentralized-scattered-no-walls"
  setup
end

to Uncentralized-inline-no-walls
  import-world "Uncentralized-inline-no-walls"
  setup
end
