RP4 CVTD NetLogo Model – Pre-Release Beta 2.0

breed [dogs dog]
breed [dogs2 dog2]

turtles-own
[
  sick?
  immune?
  healthy?
  age
  infected-time
  coupled?
  coupled-time
  partner
]

globals
[
  number-infected
  number-healthy
  number-immune
  number-vulnerable
]

;; Designates the command for the setup button.

to setup
  clear-all
  setup-turtles
  reset-ticks
end

;; Creates a number of turtles with random position. The designated number of infected turtles are instructed
;; to "get-sick". Also, it prevents the number of infected dogs from being larger than the total number of dogs
;; and the recovery time from being larger than the maximum dog age. Finally, there are two identical shapes for
;; the dogs. This is to help with the coupling code as explained later.

to setup-turtles
  create-turtles number-dogs
  [ setxy random-xcor random-ycor
    set size 1.5
    set color green
    set healthy? true
    set sick? false
    set immune? false
    set age 0 + random 5
    set coupled? false
    set coupled-time 0
    ifelse random 2 = 0
    [ set shape "dog"]
    [ set shape "dog 2"]
  ]
  if number-infected-dogs > number-dogs [set number-infected-dogs number-dogs]
  if recovery-time > maximum-dog-age [set recovery-time maximum-dog-age]
  ask n-of number-infected-dogs turtles
  [get-sick]
end

;; Instructions of how a turtle gets sick. They turn red and stay sick for a certain amount of time defined by the recovery-time slider.

to get-sick
  set sick? true
  set healthy? false
  set immune? false
  set color red
  set infected-time 0
end

;; Instructions of how a turtle gets better. They turn grey because they are now immune to the disease. There is also
;; a certain chance that the cancer will metastasize, resulting in death. This is defined as 5% from research.

to get-better
  set sick? false
  set immune? true
  set healthy? false
  set color grey
  ;if random-float 100 < 1 [die]
end

;; What happens when the user presses the "go" button. It involves the turtles moving and getting older.
;; If a turtle is sick, every move it takes, that time is added to its infected-time
;; If that infected time is greater than the time for recovery (user-defined), then it undergoes get-better.
;; Global variables are also updated (counting for the monitors and graph).
;; To simplify the coding, dogs with the shape of "dog 2" are always the ones to initiate coupling.
;; If a turtle is not coupled, it will go down to different pathways, depending on if it is sick or not. If the
;; "dog 2" dog is sick, it will go down the "sick-couple" pathway, while healthy "dog 2"'s will go down the couple pathway.
;; If a turtle is coupled and has been for longer than the user defined couple-time, then it will uncouple.

to go
  ask turtles [
    if coupled? = false [move]
    if coupled? = true
    [ set coupled-time coupled-time + 0.1]
    if sick? = true
      [set infected-time infected-time + 0.1]
    if infected-time > recovery-time [get-better]
  if coupled? = false and (healthy? = true or immune? = true) and shape = "dog 2" and (coupling-frequency > random-float 10) [couple]
  if coupled? = false and sick? = true and shape = "dog 2" and (coupling-frequency > random-float 10) [sick-couple]
  if coupled-time > coupling-time and shape = "dog 2" [uncouple]
  get-older
  ]
  update-global-variables
  tick
end

;; Moves randomly

to move
  rt random 100
  lt random 100
  fd 1
end

;; A turtle gets older with every tick (defined as 0.1 years).
;; If it's age is greater than the user-defined max dog age, it dies :(.

to get-older
  set age age + 0.1
  if age > maximum-dog-age [die]
end

;; Coupling code. All healthy "dog 2"'s will go through "couple" while all infected "dog 2"'s will go through "sick-couple".
;; Once down this path, the two turtles of different shapes next to eachother will be paired together and be surrounded by
;; a grey box. If dog 2 is healthy and its partner is sick, it's partner can infect it and vice versa.

to couple
  let potential-partner one-of (turtles-at -1 0) with [coupled? = false and shape = "dog"]
  if potential-partner != nobody
  [ set partner potential-partner
    set coupled? true
    ask partner [ set coupled? true]
    ask partner [ set partner myself]
    set pcolor grey - 3
    ask (patch-at -1 0) [set pcolor grey - 3]
    move-to patch-here
    ask partner [move-to patch-here]
    ask partner [infect]
    ]
end

to sick-couple
  let potential-partner one-of (turtles-at -1 0) with [coupled? = false and shape = "dog"]
  if potential-partner != nobody
  [ set partner potential-partner
    set coupled? true
    ask partner [ set coupled? true]
    ask partner [ set partner myself]
    set pcolor grey - 3
    ask (patch-at -1 0) [set pcolor grey - 3]
    move-to patch-here
    ask partner [move-to patch-here]
    infect
    ]
end

;; Uncoupling code. After a user-defined amount of time, a couple will break apart and will have an opportunity
;; to reproduce.

to uncouple
  set coupled? false
  set coupled-time 0
  set pcolor black
  ask (patch-at -1 0) [set pcolor black]
  if partner != nobody
  [ask partner [ set coupled-time 0]
  ask partner [ set partner nobody]
  ask partner [ set coupled? false]
  set partner nobody]
  make-babies
end

;; Infection can only take place if the dogs are coupled and one of the dogs is infected.

to infect
  if coupled? = true and partner != nobody
  [ if transmission-rate-between-dogs > random-float 200 and immune? = false
    [ ask partner [ get-sick]]]
end

;; Making babies can only take place if the dogs are coupled and the total number of dogs is less than
;; the carrying capacity. If one of the dogs is sick, then there is a chance that the offspring will be
;; infected. Since there are two shapes of dogs that can be created, there are two chances to reproduce.
;; This is why the chance is based off a random number from 0 to 400. The slider has a maximum of 200
;; and while this does not mean that every couple will have a child, it results in a similar result
;; as if a single dog could be produced based off a random number from 0 to 200. This also creates the
;; possibility that a single couple can produce two offspring.

to make-babies
  if random-float reproduction-rate > random 400 and count turtles < carrying-capacity
  [hatch-dogs 1
    rt random-float 360
    fd 1
    set age 0
    set immune? false
    set color green
    if sick? = true and transmission-rate-during-birth > random 200 [get-sick]
    ]
  if random-float reproduction-rate > random 400 and count turtles < carrying-capacity
  [hatch-dogs2 1
    rt random-float 360
    fd 1
    set age 0
    set immune? false
    set color green
    if sick? = true and transmission-rate-during-birth > random 200 [get-sick]
    ]
end

;; Updating required for the graphs and monitors to keep up with the simulation.

to update-global-variables
  if count turtles > 0
  [ set number-infected (count turtles with [sick? = true])
      set number-healthy (count turtles - number-infected)
      set number-immune (count turtles with [immune? = true])
      set number-vulnerable (count turtles - (number-infected + number-immune))]
end
