Cameroon Hunting Model

1 collaborator

Rohan Fisher (Author)

WHAT IS IT?

The wild meat trade is a regular feature in many parts of Africa. People rely on it for livelihoods and, more importantly, for food. Trade in wild meat is particularly common in west and central Africa where people regularly eat small and large antelopes, wild pigs, large rodents, fruit bats and primates, including elephants.

Overhunting of tropical wildlife for food remains an intractable issue. Donors and governments remain committed to invest in efforts to both conserve and allow the sustainable use of wildlife. Four principal barriers need to be overcome: 1) communities are not motivated to conserve wildlife long-term because they have no formal rights to benefit from wildlife, or to exclude others from taking it on their land; 2) multi-species harvests, typical of wild meat hunting scenarios, place large-bodied species at risk of extinction; 3) wildlife production cannot expand, in the same way that livestock farming can, to meet the expected growth in consumer demand; and 4) wildlife habitat is lost through conversion to agriculture, housing, transportation networks, and extractive industries.

This model has been developed to assist in understanding how hunter numbers and no-take zones (reserve areas in the current context) can affect populations of three representative wild meat species (a large rodent, a medium-sized antelope and elephant, the largest animal found in African forests). The outcomes of this model can be used to visualise the effect of overhunting on food security and livelihoods of indigenous and rural peoples dependant on wild meat as a valuable protein resource.

HOW IT WORKS

The model is populated with three hunted animal species and hunters. The three animals are:

Emin’s Rats (Cricetomys emini) - large rodents with high reproduction rates.
Duikers - Small antelope (Philantomba spp. and Cephalophus spp.) native to Sub-Saharan Africa. They are found in forested landscapes.
Elephants - long lived with slow reproduction rates

Each species has variables related to:

Life span
Reproductive Age
Number of Offspring
Area required (Carrying Capacity) for offspring to survive.

The number of hunters and reserve area can me modified.

HOW TO USE IT

Adjust the slider parameters or use the default settings.
Press the SETUP button.
Press the GO button to begin the simulation.
Change number of hunter and reserve variables. Both of these can be changed whilst the model is running.
View the plots to watch the populations and hunter catch change over time.
Adjust the reserve

THINGS TO NOTICE

Populations of different species are displayed in top-right. Fluctuations in populations will vary for different species and with the amount of reserve area.
The amount of species being caught originating from protected areas will increase as the number of hunters and amount of reserve area increases
Energy expended per total weight of bush meat caught is shown as the monitor "total catch/energy expended". This will reach a near equilibrium with different hunter and reserve settings.

THINGS TO TRY

Try running the model with no hunters, what is the equilibrium state. How does this change as you add hunters?
Does the number of starting animals influence if the population reaches equilibrium?
What number of hunters leads to extiction of different species?
How much reserve will lead to a stable elephant population?
Under what conditions does not hunting elephants lead to more or less overall species (weight) catch?
Changing the number of hunters and reserve area will impact the proportion of animals caught that originate from each zone. How does the reserve act as a source and of bush meat when hunter numbers are high?

EXTENDING THE MODEL

Add village origin and end points for hunter journeys.
Add Poaching hunters going into reserve areas.

RELATED MODELS

Look at the Wolf-Sheep model for a basic predator prey model example.
Look at Bug Hunt Consumers for a simpler version of this model that no predators or reserves.

CREDITS AND REFERENCES

Developed by Rohan Fisher Rohan.fisher@cdu.edu.au Charles Darwin University (2019)

References

Fa JE, Brown D. (2009). Impacts of hunting on mammals in African tropical moist forests: a review and synthesis. Mammal Review 39, https://doi.org/10.1111/j.1365-2907.2009.00149.x
Wilkie DS, Wieland M, Boulet H, Le Bel S, van Vliet N, Cornelis D, BriacWarnon V, Nasi R, Fa JE. (2016). Eating and conserving bushmeat in Africa. African Journal of Ecology. 54(4):402-14.

HOW TO CITE

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

globals
[

;  rat-reproduce-age      ;;  min age of rats before they can reproduce
;  duiker-reproduce-age  ;;  min age of elephants before they can reproduce
elephant-reproduce-age     ;;  min age of duiker before they can reproduce
;
;  rat-max-age           ;;  max age of rats before they automatically die
;  duiker-max-age          ;;  max age of duiker before they automatically die
  elephant-max-age       ;;  max age of elephants before they automatically die

  max-rats-offspring              ;; maximum number of offspring per reproductive event for a rat
  max-duikers-offspring             ;; maximum number of offspring per reproductive event for a bird
  max-elephants-offspring          ;; maximum number of offspring per reproductive event for an elephant


  rat-energy              ;; maximum number of offspring per reproductive event for a rat
  duiker-energy             ;; maximum number of offspring per reproductive event for a bird
  elephant-energy          ;; maximum number of offspring per reproductive event for an elephant

  rat-reproduce-interval
  duiker-reproduce-interval
  elephant-reproduce-interval

  rat-range           ;;  max age of rats before they automatically die
  duiker-range          ;;  max age of duiker before they automatically die
  elephant-range      ;;  max age of elephants before they automatically die

  total-catch-rat
  total-catch-duiker
  total-catch-elephant

;  rat-cc
;  duiker-cc
;  elephant-cc

  Origin-Reserve
  Origin_Hunting_Area

  border

]

breed [ duikers duiker ]
breed [ elephants elephant ]
breed [ rats rat ]
breed [ hunters hunter ]  ;;  turtles that mark the location of where a rat was removed from disease.

turtles-own [ current-age max-age starting-patch distance-from-home time-since-birth place-of-birth]       ;; these three variables are used for rats, elephants, and duiker
patches-own [reserve]

to setup
  clear-all
; set rat-reproduce-age 20
; set rat-max-age  40
  set  max-rats-offspring   3
  set rat-range 12
;
; set duiker-reproduce-age 40
; set duiker-max-age  60
  set  max-duikers-offspring 2
  set duiker-range 15

  set elephant-reproduce-age 200
  set elephant-max-age  1000
  set  max-elephants-offspring 1
  set elephant-range 60

  set rat-reproduce-interval 7
  set duiker-reproduce-interval 10
  set elephant-reproduce-interval 50


  set rat-energy 30
  set duiker-energy 50
  set elephant-energy 1000


  set-default-shape rats "mouse"
  set-default-shape duikers "fox"
  set-default-shape elephants "mammoth"
  set-default-shape hunters "person"

  ask patches [set pcolor green]
  ask patches with [pxcor > (55 - reserve-size)] [set pcolor 53]
  ask n-of 500 patches  [sprout 1 [set color 54 set size 2 set shape "grass"]]

  ask patches with [ count neighbors != 8 ] [set pcolor 54.5]

  add-rats
  add-duiker
  add-elephants
  add-hunters
  reset-ticks
end

to go
 if ticks >= 3000 and after-3000 [stop]
  ask rats [
    rats-live
    reproduce-rats]
  ask duikers [
    duiker-live
    reproduce-duikers]
  ask elephants [
    elephants-live
    reproduce-elephants]
  ask hunters [hunters-live]
  if  (count elephants + count rats + count duikers) = 0 and on-extiction  [stop]
  tick
end

to add-rats ;; setup rats procedure to add rats based on initial settings
  create-rats initial-number-rats [  ;; create the rats, then initialize their variables
    set color white
    set current-age 0  + random rat-max-age       ;;don't start out with everyone at the same age
    set max-age rat-max-age
    set time-since-birth 100
    set size 2
    setxy random-pxcor random-pycor
    set starting-patch patch-here
  ]
end

to add-duiker ;; setup duiker procedure
  create-duikers initial-number-duikers  ;; create the duikers, then initialize their variables
  [
    set color brown
    set current-age 0  + random duiker-max-age      ;;don't start out with everyone at the same age
    set max-age duiker-max-age
    set time-since-birth 100
    set size 3
    setxy random-pxcor random-pycor
    set starting-patch patch-here
  ]
end

to add-elephants
  create-elephants number-of-elephants ;; elephants the rats, then initialize their variables
  [
    set color grey
    set current-age 0  + random elephant-max-age     ;;don't start out with everyone at the same age
    set max-age elephant-max-age
    set time-since-birth 100
    set size 6
    setxy random-pxcor random-pycor
    set starting-patch patch-here
   ]
end

to add-hunters
  ask n-of number-of-hunters patches with  [pcolor = green]
  [sprout-hunters 1  [ set color black     set size 3
  ]]
end

to rats-live ;; rats procedure
  move-rats
    reproduce-rats
    set current-age (current-age + 1)
      set time-since-birth (time-since-birth + 1)
    death
end

to duiker-live ;; duiker procedure
  move-duiker
  reproduce-duikers
  set current-age (current-age + 1)
      set time-since-birth (time-since-birth + 1)
  death
end

to elephants-live ;; elephants procedure
    move-elephants
    reproduce-elephants
    set current-age (current-age + 1)
    set time-since-birth (time-since-birth + 1)
 death
end

to hunters-live ;; elephants procedure
    move-hunters
    hunter-catch-animal
  set current-age (current-age + 1) ;this is used as a proxy for hunting effort - the amount of time spent looking for animals
end

to move-rats  ;; rats procedure

  ifelse [pcolor] of patch-here = 54.5
    [    rt random 140
         lt random 140
      fd .5 ]

    [ifelse distance starting-patch > rat-range
    [face starting-patch]
    [ rt random 90  lt random 90 ]
  ]

  fd 1
end

to move-duiker  ;; duiker procedure
    ifelse [pcolor] of patch-here = 54.5
    [    rt random 140
         lt random 140
      fd .5 ]

   [ ifelse distance starting-patch > duiker-range
    [face starting-patch]
    [ rt random 90  lt random 90 ]
  ]
    fd 1
end

to move-elephants  ;; elephants procedure
  ifelse [pcolor] of patch-here = 54.5
    [    rt random 140
         lt random 140
      fd .5 ]

    [ifelse distance starting-patch > elephant-range
    [face starting-patch]
    [ rt random 90  lt random 90 ]
  ]

  fd 1
end

to move-hunters ;;
    ifelse [pcolor] of patch-here = 54.5 or [pcolor] of patch-here = 53 [
    rt 180  ]
    [ rt random 40
      lt random 40   ]
  fd 1
end

to hunter-catch-animal  ;; duiker procedure
    if (any? rats in-radius 4 )
        [ask one-of  rats in-radius 4 [  set total-catch-rat (total-catch-rat + rat-energy)
        if place-of-birth = 2  [set Origin-Reserve Origin-Reserve + 1]
         if place-of-birth = 1 [set Origin_Hunting_Area Origin_Hunting_Area + 1] die]]

    if (any? duikers in-radius 4 )
        [ask one-of  duikers in-radius 4 [ set total-catch-duiker (total-catch-duiker + duiker-energy)
         if place-of-birth = 2  [set Origin-Reserve Origin-Reserve + 1]
         if place-of-birth = 1 [set Origin_Hunting_Area Origin_Hunting_Area + 1] die]]

     if hunt-elephants [
      if (any? elephants in-radius 5 )
      [ask one-of  elephants in-radius 5 [die]  set total-catch-elephant (total-catch-elephant + elephant-energy)  ]]
end

to reproduce-rats  ;; rats procedure
  let number-offspring (random (max-rats-offspring + 1)) ;; set number of potential offspring from 1 to (max-rats-offspring)
  if ( current-age > rat-reproduce-age and time-since-birth > rat-reproduce-interval and random 4 = 1  and ((count rats in-radius rat-cc) < 3))
  [ set time-since-birth 0
    hatch number-offspring
      [
        set size 2
        set color white
        set current-age 0
        set time-since-birth  1000
        set shape "mouse"
        rt random 360 fd 7
        set starting-patch patch-here
        ifelse pxcor > (55 - reserve-size) [set place-of-birth 2 ] [set place-of-birth 1 ] ;; born in or outside a protected area
      ]    ;; hatch an offspring set it heading off in a random direction and move it forward a step
    ]
end

to reproduce-duikers

  let number-offspring (random (max-rats-offspring + 1)) ;; set number of potential offspring from 1 to (max-rats-offspring)
  if ( current-age > duiker-reproduce-age and time-since-birth > duiker-reproduce-interval and random 4 = 1  and ((count duikers in-radius duiker-cc) < 3))
  [ set time-since-birth 0
    hatch number-offspring
      [
        set size 3
        set color brown
        set current-age 0
        set time-since-birth  1000
        set shape "fox"
        rt random 360 fd 7
        set starting-patch patch-here
        ifelse pxcor > (55 - reserve-size) [set place-of-birth 2 ] [set place-of-birth 1 ] ;; born in or outside a protected area
      ]    ;; hatch an offspring set it heading off in a random direction and move it forward a step
    ]
end

to reproduce-elephants  ;;
   if ( current-age > elephant-reproduce-age and time-since-birth > elephant-reproduce-interval and random 3 = 1  and ((count elephants in-radius 70) < 3))
  [ set time-since-birth 0
    hatch 1
      [
        set size 6
        set color grey
        set current-age 0
        set time-since-birth  1000
        set shape "mammoth"
        rt random 360 fd 7
        set starting-patch patch-here
        ifelse pxcor > (55 - reserve-size) [set place-of-birth 2 ] [set place-of-birth 1 ] ;; born in or outside a protected area
      ]    ;; hatch an offspring set it heading off in a random direction and move it forward a step
    ]
end

to death  ;; common procedure for rats duiker & elephants to die
  if (current-age > max-age)
  [ die ]
end



; Copyright 2011 Uri Wilensky.
; See Info tab for full copyright and license.

There are 2 versions of this model.

		Uploaded by	When	Description	Download
		Rohan Fisher	over 6 years ago	Spelling correction	Download this version
		Rohan Fisher	over 6 years ago	Initial upload	Download this version
